電液換向閥H-4WEH25E6X/6HG24N9ETK4



液壓機NG25電液換向閥H-4WEH25E6X/6HG24N9ETK4

電液換向閥是由電磁換向閥作先導閥與液動換向閥組合而成，由電磁閥引進油液，推動主滑閥運動，使主油路換向。主要用于改變油流方向，改變油馬達旋轉方向，和油缸的運動方向等。也可用以完成卸荷和順序動作等用途。適用于大流量的液壓系統。液動閥換向的快慢可用其控制油路中的單向節流閥來調節。

原理：通電時，電磁線圈產生電磁力把關閉件從閥座上提起，閥門打開；斷電時，電磁力消失，彈簧把關閉件壓在閥座上，閥門關閉。
特點：在真空、負壓、零壓時能正常工作，但通徑一般不超過25mm。



說明事項
1.產品可任意安裝，優先考慮水平位置。
2.液壓系統所用介質必c須過濾，過濾精度至少20μm。
3.固定螺釘請按樣本中所列參數選用。
4.與閥連接的表面，粗糙度要求Ra0.8，平面度要求0.01/100mm
工作原理：。。當兩個電磁閥線圈通電時，平衡孔回路關閉，泄流孔回路打開，活塞上腔泄壓，活塞上行，閥門打開。反之，活塞下行，閥門關閉。在閥門開啟和關閉過程中，可將流量（流速）信號及閥塞位置信號傳送給計算機，經過計算機處理后發出相應的指令，控制兩個電磁導閥的通、斷電狀態，使活塞的上下腔的液壓差產生變化，從而將活塞控制在所需的開啟高度上，實現對管道介質流量的控制。
